Cartridge
Description
Vented Pilot-To-Open Check Valve
Specifications
Cavity T-22A
Series 2
Capacity 30 gpm
Maximum Operating Pressure 5000 psi
Pilot Ratio 3:1
Maximum Valve Leakage at 110 SUS (24 cSt) 1 drops/min.
Valve Hex Size 1 1/8 in.
Valve Installation Torque 45 - 50 lbf ft
Adjustment Screw Internal Hex Size 1/8 in.
Locknut Hex Size 7/16 in.
Model Weight 0.66 lb.
Seal kit - Cartridge Buna: 990022007
Seal kit - Cartridge Polyurethane: 990022002
Seal kit - Cartridge Viton: 990022006
Features
Approximately 1 drop (0,07 cc) of fluid will pass from the pilot area to the vented spring chamber every 4000 cycles.
For models with manual load release control option, turn load release clockwise to release load.
Provides hose break protection, prevents loads from drifting and positively locks pressurized loads.
Extremely low leakage. The seat and poppet are heat treated for long life. If the load drifts due to the valve, the seat has probably been damaged by contamination and the valve should be replaced.
Sealed pilot for use in circuits where cross port leakage is undesirable.
Port 4 (vent) should never be blocked as seal weepage will eventually cause valve to malfunction.
Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
