BUTTON CONTROL
Description
Three way miniature Push Button valve, normally closed, spring return with 10-32 UNF ports. All TAC Push Button valves feature an attractive, work hardened SST button above a 15/32-32 threaded collar. Feature permits panel mounting or acceptance of a variety of TAC operators. Button bottoms out on collar to prevent valve overstroke. Compact. Rugged.
Specifications
Media: Air
Valve Function: 3-way, Spring Return
Piping Type : Inline, Direct Piping
Port Size: 10-32 UNF
Number of Ports: 3 ports
Number of Positions: 2 positions
Options Included: Hardened Button for Manual or Mechanical use, Panel Mounting Hardware
Approx Size (in) HxWxD: 1.45 x 0.56 HEX
Type of Operation: Push button
Flow - SCFM @ 100 psig: 7.5
Flow - LPM @ 6.9 bar: 212
ESEOD (orifice) - in (mm): 0.0845 (2.16)
Flow Coefficient (Cv): 0.13
Lubrication: Not required
Pressure Range (psi): 0-125
Force to Actuate (lbs): 2.4 4.8
Operating Speed (cycles/min): 900
Ambient Temperature Range (°F): -20~180
Wetted Materials: Brass, SST, Buna N
Weight (oz): 1.3
Features
Accepts Air Pilot Operators (sold separately): 34A, 34AR, 34AS, 34ASR
Accepts Manual Operators (sold separately): 34F, 34T
Accepts Mechanical Operators (sold separately): 34B, 34C, 34CW, 34CH
