Product Overview
Modular Throttle Valve
Description
HQ, KQ and JPQ are flow throttling valves, not compensated, and with check valve to allow free flow in the opposite direction.
The flow adjustment is done by turning the setting screw in the normal model.
Specifications
Valve size and max flow:
HQ-0 = size 06, flow up to 25 l/min for /U
option, up to 80 l/min for standard
KQ-0 = size 10, flow up to 160 l/min
JPQ-2 = size 16, flow up to 200 l/min
JPQ-3 = size 25, flow up to 300 l/min
Mounting surface:
ISO 4401 size 06, 10, 16 and 25
Max pressure: 350 bar (HQ, JPQ) 315 bar (KQ)
Features
Optional versions with a graduate micrometer knob are available on request. Clockwise rotation increases the throttling (passage reduced).
*Please note that image representation may only represent a product series with particular items. The buyers responsibility is to ensure the product SKU matches their specifications before purchase.
