Product Overview
Pressure Transducer E-ATR-8
Description
Pressure transducers type E-ATR-8 analog, for open and closed loop systems.
E-ATR-8
This pressure transducers measure the static and dynamic pressure of the hydraulic fluid, supplying a voltage or current output signal. The sensor is composed by a thin-film circuit, with high resistance to overloads and pressure peaks.
The integrated electronic circuit supplies an amplified voltage or current output signal, proportional to the hydraulic pressure, with thermal drift compensation.
E-ATR-8 equip pressure control digital proportional valves with integral transducer and electronics, REB/RES execution.
Specifications
They are also used in association with other Atos digital proportionals to perform closed loop pressure controls:
• variable displacement axial piston
pumps, PE(R)S execution
• directional control valves with additional closed loop pressure control, SPand SF options on TES/LES execution
Features
Features:
• Factory preset and calibrated
• Standard 5 pin M12 main connector
• IP67 protection degree
• CE mark according to EMC directive
*Please note that image representation may only represent a product series with particular items. The buyers responsibility is to ensure the product SKU matches their specifications before purchase.
