Product Overview
Cartridge
Description
The single ball shuttle connects the higher of two work ports to the signal or common port. The signal is sensed at port 2. Shuttle cartridges feature hardened steel balls and seats for excellent wear characteristics and contamination tolerance. The single ball allows for the decay of the pressure signal when both load ports drop to a lower pressure. Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals. Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
Specifications
Cavity T-11ASeries 1Capacity 2.5 gpmMaximum Operating Pressure 5000 psiMaximum Valve Leakage at 110 SUS (24 cSt) 5 drops/min.Valve Hex Size 7/8 in.Valve Installation Torque 30 - 35 lbf ftModel Weight 0.25 lb.Seal kit - Cartridge Buna: 990011007Seal kit - Cartridge EPDM: 990011014Seal kit - Cartridge Polyurethane: 990011002Seal kit - Cartridge Viton: 990011006
*Please note that image representation may only represent a product series with particular items. The buyers responsibility is to ensure the product SKU matches their specifications before purchase.
