Product Overview
CUP BEL 2in. B-MT BLK
Description
General purpose single bellows vacuum cups best used on moderatly flat, dry surfaces
- Moderate compression distance allows for minor misalignments
Specifications
-Diameter (in) 2.26
-Holding Capacity - Horizontal Wet (lbf) 4.5
-Weight (oz) 2
-Cup Size 2.00 in
-Holding Capacity - Horizontal Dry (lbf) 8.5
-Mount 3/8 NPT
-Material Nitrile
-Holding Capacity - Vertical Lift (kg) 11.8
-Holding Capacity - Vertical Lift (lbf) 26
-283-HTS_TARIFF_CODE 40169991
-Shape Round
-Chemical Resistance Oil, water, grease, hydraulic fluid, alcohol
-Durometer 60 (Black)
-Distributor Group End Effectors
-Product Series AC/BT
-Product Function Robotic Tooling
-Product Type Bellows
*Please note that image representation may only represent a product series with particular items. The buyers responsibility is to ensure the product SKU matches their specifications before purchase.
