Product Overview
Accessory
Description
The shelf life for this cartridge seal kit is twenty years from date of purchase. This date will be printed on the kit packaging.
Specifications
Series 3
Cartridge Thread 1-14 UNS
Valve Hex Size 1 1/4 in.
Valve Installation Torque 150 - 160 lbf ft
Cavity T-17A
Features
Part Description Quantity View
500-101-120 O-Ring 1 C
500-101-126 O-Ring 1 A
500-102-124 O-Ring 1 B
515-102-121 Backup Ring 2 C
515-102-123 Backup Ring 1 B
515-102-126 Backup Ring 1 A
*Please note that image representation may only represent a product series with particular items. The buyers responsibility is to ensure the product SKU matches their specifications before purchase.
